Shenzhen Dezhen Telecommunication Technology Co.,Ltd
professional manufacturer of mobile signal jammer ,high power jammer and min signal booster!
 |
| Place of Origin: | China |
| Brand Name: | DEZHEN |
| Certification: | CE,FCC |
| Model Number: | DZ-WT700369 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | negotiated price |
| Packaging Details: | carton or wooden case |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 2000 pcs per years |
| Jamming Range: | 50-800 Meters | Total Output Power: | 600~1200W |
|---|---|---|---|
| Power Consumption: | 330W | Working Time: | 24 Hours/365days Continuously |
| Dimension: | 640×540×550 Mm | Weight: | 75 Kg |
| Humidity: | 5%-95% | Working Temp: | -20℃ To +55℃ |
| Highlight: | Directional Antennas Vehicle Bomb Jammer,Military Vehicle Bomb Jammer,Portable Cellular Signal Detector |
||
Military VVIP Protection Defence Vehicle Bomb Jammer Portable Cell Phone Signal Jammer
Product description :
This device can configured more than 11 different jamming modules, and the jamming frequency can be more than 11 Bands. This High power Jammer 11 bands jamming frequency modules can provide up to 1500 Watt output power maximum. The Bomb jammer is very easily installed and operated. The device can be powered by AC mains or a suitable DC power source. The general design of the system meets military requirements and international quality standards.
This cell phone jammer's effective jamming area is influenced by circumstance around users, such as the distance or locations of the cell tower and the obstacles, between cell tower and the cell phone jammer. In the normal condition, the cell phone jammer will work very less jamming area, when the distance is near or very close the cell tower or cell base stations. As well as, if there are obstacles and walls between the cell tower and the cell phone, the cell phone jammer will give less blocking area.
Technical Specifications:
11 bands for option: The frequencies can be from 20-6000MHZ
| Output Interface | Frequency Range | Out Power | RF Output dBm |
| CH1 | 20-108MHz | Wireless ,FM Radio | 100W |
| CH2 | 135-174MHz | Wilkie-talkie(VHF) | 100W |
| CH3 | 300-400MHz | Remote Control, Drone | 100W |
| CH4 | 400-470MHz | Wilkie-talkie(UHF),Car alarm | 100W |
| CH5 | 851-894MHz | CDMA | 100W |
| CH6 | 925-960MHz | GSM | 100W |
| CH7 | 1570-1580MHz | GPSL1 | 50W |
| CH8 | 1805-1920MHz | DCS,PCS | 100W |
| CH9 | 2110-2170MHz | WCDMA | 50W |
| CH10 | 2400-2485MHz | WIFI,Drone,Bluetooth | 50W |
| CH11 | 5725-5850MHz | WIFI,Drone | 15W |
| Jamming Radius: | 50-800M, the jamming radius still depends on the strength signal in given area | ||
| HS Code: | 8543709200 | ||
| Total output power: | 600~1200W | ||
| Power Consumption: | 330W | ||
| Type: | Vehicle Jammer | ||
| Dimension: | 640×540×550 mm | ||
| Packing: | Neutral Packing | ||
| Signal Jammer for: | 20 - 6000MHz Cell Phone Signal Jammer | ||
| Power supply: | AC110 240V | ||
| Weight: | 75 Kg | ||
| Humidity: | 5%-95% | ||
| Working Temp: | -20℃ to +55℃ | ||
RF Characteristics:
| RF Characteristics | Description |
| Output Power | 915 Watts |
| Internal Modulation | FM Hopping Frequency |
| Signal Source | VCO Synthesized |
| Power Supply | AC110-240V,24V or 48V DC |
| Modules Per Unit | 11 |
| Contol | ON/OFF with Switch |
| Monitoring | Adjusted output power by DIP switch |
| Antenna | External- Omni-directional for 360° |
| Power Amplifier Protectors | Full VSWR Protector |
| Operating Hours | Unlimited |
Applicable Area:
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
Contact Person: Mr. Yuen (+86 13316806155)
Tel: +86 13316806155
Fax: 86-133-16806155
