Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer

Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer

  • Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer
  • Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer
  • Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer
  • Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer
Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer
Product Details:
Place of Origin: China
Brand Name: DEZHEN
Certification: CE,FCC
Model Number: DZ-WT700205
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: negotiated price
Packaging Details: carton or wooden case
Delivery Time: 3-4 weeks
Payment Terms: L/C, T/T
Supply Ability: 2000 pcs per years
Contact Now
Detailed Product Description
Type: Bomb Jammer Signal Jammer For: 20 - 6000MHz Cell Phone Signal Jammer
Jamming Area: 50-800 Meters Working Time: 24 Hours/365days Continuously
Dimension: 640×540×550 Mm Weight: 75 Kg
Power Consumption: 330W Packing: Box
High Light:

GSM Signal Jamming Device

,

GPS WiFi Signal Jammer

600W RF Cell Phone Reception Blocker CE/FCC Approval , Cell Phone Military Portable Signal Jammer





Product description :



This device is not only bomb jammers, but also high power portable DDS convoy jamming system, portable RF jammer,portable vehicle bomb jammer. This jammer can implementing the most effective and reliable RF jamming technology and equipped with a fully-

integrated broadband jamming system.



It can cove all RF communication Frequencies between 20MHz to 3600MHz continuously and simultaneously.



Features:

1. High-power portable multi-band jammer.


2. Field programmability for rapid adjustment frequence with output Watt.

3. Modular construction for easy maintenance,repair and upgrade.

4. Jammer up to five different jamming modules simultaneously,and cover up to 10 different frequency bands.

5. Each module with LED display to show its working frequency ,output power and etc.

6. 250-300 watt total RF output power.

7. Equipped with a remote control unit. The operator can ON/OFF each module through the wired remote controller.

8. Fully portable trolley-type case.

9. Internal battery, AC mains or DC power.

10. External LED display to indicate the batterylevel.

11. Designed with external backup battery input, adapted to external battery. Facilitating to change the battery timely for field use.



Technical Specifications:



11 bands for option: The frequencies can be from 20-6000MHZ



Output Interface Frequency Range Out Power RF Output dBm
CH1 20-108MHz Wireless ,FM Radio 100W
CH2 135-174MHz Wilkie-talkie(VHF) 100W
CH3 300-400MHz Remote Control, Drone 100W
CH4 400-470MHz Wilkie-talkie(UHF),Car alarm 100W
CH5 851-894MHz CDMA 100W
CH6 925-960MHz GSM 100W
CH7 1570-1580MHz GPSL1 50W
CH8 1805-1920MHz DCS,PCS 100W
CH9 2110-2170MHz WCDMA 50W
CH10 2400-2485MHz WIFI,Drone,Bluetooth 50W
CH11 5725-5850MHz WIFI,Drone 15W
Jamming Radius: 50-800M, the jamming radius still depends on the strength signal in given area
HS Code: 8543709200
Total output power: 600~1200W
Power Consumption: 330W
Type: Vehicle Jammer
Dimension: 640×540×550 mm
Packing: Neutral Packing
Signal Jammer for: 20 - 6000MHz Cell Phone Signal Jammer
Power supply: AC110 240V
Weight: 75 Kg
Humidity: 5%-95%
Working Temp: -20℃ to +55℃



RF Characteristics:

RF Characteristics Description
Output Power 915 Watts
Internal Modulation FM Hopping Frequency
Signal Source VCO Synthesized
Power Supply AC110-240V,24V or 48V DC
Modules Per Unit 11
Contol ON/OFF with Switch
Monitoring Adjusted output power by DIP switch
Antenna External- Omni-directional for 360°
Power Amplifier Protectors Full VSWR Protector
Operating Hours Unlimited




Omni directional antenna 600W RF Cell Phone Reception Blocker Approval Cell Phone Military Portable Signal Jammer 0
