Place of Origin: | China |
Brand Name: | DEZHEN |
Certification: | CE |
Model Number: | DZ-WT500317 |
Minimum Order Quantity: | 1 PC |
---|---|
Price: | negotiated price |
Delivery Time: | 25 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100pieces/month |
Frequency For: | GSM,CDMA,Dcs/PCS,3G,4G Lte,4G Wimax | Application Area: | Prison, Military Units, Police, Bomb Disposal |
---|---|---|---|
Output Power: | Up To 80-350Watt | Jamming Range: | Up To 25~300M |
Battery: | Built-in Standby Battery Can Used For 90~120 Minutes | Cooling System: | Active "smart" With Integrated Incoming Air Filter |
Highlight: | Prison Cellular Signal Blocker,WIFI Cellular Signal Blocker,350 Watt Military Gps Jammer |
Military High Power Durable Waterproof Outdoor Prison Jammer 4G WIFI GPS Cell Phone Signal Jammer
It can effectively shield (interference) up to 25-300 meters all indoor and outdoor signals such as
2G / 3G / 4G mobile phone signal and intercom, remote bomb, WiFi signal, shielding eraser, SMS pen,
stealth headphones, watches cheating, glasses probe wireless signal, to prevent candidates cheat, protect
the venue quiet, and to prevent bomb attacks.
Advantages:
1, Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
2, Heat sink designing combing with the fans to make system in a cooling status.
3,,Special technology to prevent interference between each frequency band.
4,Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
5, Frequency bands and output power selectable.
6,Each frequency band controlled by independent RF ON/OFF switches.
Specifications:
Output Interface | Output Frequency |
CH1 | -CDMA: 851-960MHz /-GSM: 925-960MHz |
CH2 | -DCS: 1805-1880MHz |
CH3 | -PCS: 192-1990MHz |
CH4 | -3G: 2110-2170MHz |
CH5 | -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU) |
CH6 | -4G LTE: 725-770MHz(US) or 790-826MHz(EU) |
Type: | Prison Jammer |
Output Channel: | 6 channels |
Output power: | Up to 80-350Watt ( For customization, you can select the out put power. ) |
Jamming Range | Up to 25~300M (It depends on the signal strength in the given area) |
Jammer Module Number | 6 |
HS Code: | 8543709200 |
Packing: | Box |
Dimension (not including antennae) | 36.5*25*48cm |
Working time: | 24 hours/365days continuously. |
Weight (without antennae): | Up to 30KG |
Control: | Wireless Management Control |
Power Adjustment: | Multi level potentiometer |
Power supply: | AC110-240V, DC-24V |
Cooling system: | Active "smart" with integrated incoming air filter |
Antennae type: | External high gain Omni directional Antenna |
Battery | 24V,30AH,Built-in standby battery can used for 90~120 minutes |
We could supply customized service by your detail requirements about frequencies setting. All 6 Frequency modules we can mix very flexibly.Frequency Ranges Selectable:
CDMA 800: | 851-894MHz |
GSM 900: | 925-960MHz |
DCS 1800: | 1800-1880MHz |
PHS 1900: | 1920-1990MHz |
3G 2100(UMTS): | 2110-2170MHz |
WIFI 2.4G Bluetooth: | 2400-2500MHz |
WiFi3.6G: | 3500-3600MHz |
Wi-Fi5.2G: | 5100-5500MHz |
WIFI 5.8G | 5725-5850MHz |
4G/LTE 700M: | 725-770MHz(US) |
4G/LTE 800M: | 790-826MHz(EU) |
4G Wimax: | 2300-2400MHz(US) |
4G Wimax: | 2620-2690MHz(EU) |
GPS/L1: | 1500-1600MHz |
GPS/L2: | 1200-1300MHz |
GPS/L3: | 1300-1400MHz |
GPS/L4: | 1100-1200MHz |
VHF: | 135-174MHz |
UHF: | 400-470MHz |
Lojack: | 167-175MHz |
RF315: | 315MHz |
RF433: | 433MHz |
RF868: | 868MHz |
Following is the standard parameters for this prison jammer,OEM/ODM and customized frequencies are
accpetable as well.
Application:
• Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations,
detention centers, interrogation rooms, courts,Reform-through-labour teams, conference rooms, movie
theaters, churches, libraries, school dormitories;ect.
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile
political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
