Place of Origin: | China |
Brand Name: | DEZHEN |
Certification: | CE.FCC... |
Model Number: | DZ-WT702016 |
Minimum Order Quantity: | 1pc |
---|---|
Price: | negotiated price |
Packaging Details: | carton or wooden case |
Delivery Time: | 3-4 weeks |
Payment Terms: | L/C, T/T |
Supply Ability: | 100 pieces/month |
Jamming Range: | Up To 500m | Total Output Power: | 600~1200W |
---|---|---|---|
Type: | Outdoor Jammer | Power Supply: | 50 To 60Hz, 100 To 240V AC |
Packing: | Neutral Packing | Design: | Customized Jammer |
Application Area: | Military Units, Prison,Police, Bomb Disposal | Feature: | Customize All Frequency Signal |
Highlight: | VIP Protection Military Gps Jammer,12 Bands Military Gps Jammer,RF Cellular Signal Jammer |
12 Bands Full Frequency VIP Protection Security Cell Phone Signal Waterproof Outdoor Jammer
Product Description:
This signal Jammer device is a high-tech product developed by our company in combination with
advanced technology at home and abroad, aiming at the continuous development of communication
system, according to the meticulous development of domestic and foreign communication hand section.
Within a radius of 50 to 200 meters, all 2G / 3G / 4G mobile phone signals and televisions, remote
control bombs and WiFi signals, blocking eraser, text pen, invisible headphones, watches cheating,
glasses probe wireless signals, etc., can be effectively blocked (interfered with) inside and outside
the room. Put an end to cheating students, ensure the quiet venue, prevent bomb attacks, protect dignitaries.
Features
1. Perfect self protection function,When the equipment overheating, output power, standing wave and so on
fault alarm, The jammer will automatically turn off the failed module, avoid jammer damage.
2.All ports use waterproof aviation connector, using professional waterproof casing, no need to worry wind and rain;
3.Integrated remote control system, by the Internet remote maintenance, don’t need personnel arrived at the scene;
4.Used ultra wideband interference technology.
5.Effective power( Channel power) high, large radius coverage range.
6.Effective subsection, only jamming downlink, will not cause interference to the base station.
7.Import components, slow start circuit design can avoid mechanical switch to produce strike a light phenomenon,
high level of integration work stability.
Specification:
Output Interface | Output Frequency | RF Output watt |
CH1 | 20-80mhz | 100W |
CH2 | 80-200MHz | 100w |
CH3 | 200-500MHz | 100w |
CH4 | 500-1000MHz | 50w |
CH5 | 1000-1500MHz | 50w |
CH6 | 1500-2000MHz | 50w |
CH7 | 2000-2500MHz | 50w |
CH8 | 2500-3000MHz | 50w |
CH9 | 850-960MHz | 50w |
CH10 | 1805-1880MHz | 50w |
CH11 | 1880-1990MHz | 50w |
CH12 | 2010-2125MHz | 50w |
Total output power | 600~1200W | |
Jamming range | up to 500m,still depends on the strength signal in given area | |
Jammer Module Number | 12 | |
External double channel directional panel antennas | all the TX frequency covered down link only | |
Power supply | 50 to 60Hz, 100 to 240V AC | |
With AC adapter | (AC100-240V-DC27V) | |
Dimension | 420×480×130 mm | |
Design | Customized Jammer | |
HS Code | 8543709200 | |
Packing | Neutral Packing |
We could supply customized service by your detail requirements about frequencies setting. All 6-12
Frequency modules we can mix very flexibly.
CDMA 800: | 851-894MHz |
GSM 900: | 925-960MHz |
DCS 1800: | 1800-1880MHz |
PHS 1900: | 1920-1990MHz |
3G 2100(UMTS): | 2110-2170MHz |
WIFI 2.4G Bluetooth: | 2400-2500MHz |
WiFi3.6G: | 3500-3600MHz |
Wi-Fi5.2G: | 5100-5500MHz |
WIFI 5.8G | 5725-5850MHz |
4G/LTE 700M: | 725-770MHz(US) |
4G/LTE 800M: | 790-826MHz(EU) |
4G Wimax: | 2300-2400MHz(US) |
4G Wimax: | 2620-2690MHz(EU) |
GPS/L1: | 1500-1600MHz |
GPS/L2: | 1200-1300MHz |
GPS/L3: | 1300-1400MHz |
GPS/L4: | 1100-1200MHz |
VHF: | 135-174MHz |
UHF: | 400-470MHz |
Lojack: | 167-175MHz |
RF315: | 315MHz |
RF433: | 433MHz |
RF868: | 868MHz |
Application:
bomb squad,anti-terrorism units,anti-drag units,anti-riot force,meeting halls,infantry,military security force,SWAT team,the EOD team,checkpoints,hostage negotiations,border control,etc...
Monitor software function: (Option)
· Remote control switches of each machine.
· Remote viewing each machine working state.
· The power output of each machine remote adjustment.
· Remote viewing offline log of each machine.
· Mail receiving each machine working state.
· The system can set permissions to log on.
Terms and conditions:
Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year : 5% of total for each years. |
