Place of Origin: | China |
Brand Name: | DEZHEN |
Certification: | CE |
Model Number: | DZ-WT500174 |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | negotiated price |
Packaging Details: | carton or wooden case |
Delivery Time: | 25 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100pieces/month |
Control: | Wireless Management Control | Type: | Waterproof Jammer |
---|---|---|---|
Antenna: | Directional Or Omnidirectional Antennas Option | Packing: | Box |
Weight (without Antennae): | Up To 35KG | Output Power: | Up To 80-350Watt |
Size: | 36.5*25*48cm | Jamming Range: | Up To 25~300M |
Highlight: | 350W Mobile Phone Signal Blocker,GSM Mobile Phone Signal Blocker,RF Cellular Signal Jammer |
Multi Band Mobile Phone Signal Blocker GSM 4G 350W Wireless Management Control
Product Description
Outdoor Waterproof Jamming System is specially designed for blocking all RF cellular networks and all kinds of cellular standard in the world, includes 2g/3g/4g/5g/ WIFI 2.4g & 5.8g with waterproof function to provide your privacy, security and peace in all ways. It has been used widely in prisons/Jails and schools in many countries.
Advantages:
1, Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
2, Heat sink designing combing with the fans to make system in a cooling status.
3,,Special technology to prevent interference between each frequency band.
4,Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
5, Frequency bands and output power selectable.
6,Each frequency band controlled by independent RF ON/OFF switches.
Specifications:
Output Interface | Output Frequency |
CH1 | -CDMA: 851-960MHz /-GSM: 925-960MHz |
CH2 | -DCS: 1805-1880MHz |
CH3 | -PCS: 192-1990MHz |
CH4 | -3G: 2110-2170MHz |
CH5 | -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU) |
CH6 | -4G LTE: 725-770MHz(US) or 790-826MHz(EU) |
Type: | Prison Jammer |
Output Channel: | 6 channels |
Output power: | Up to 80-350Watt ( For customization, you can select the out put power. ) |
Jamming Range | Up to 25~300M (It depends on the signal strength in the given area) |
Jammer Module Number | 6 |
HS Code: | 8543709200 |
Packing: | Box |
Dimension (not including antennae) | 36.5*25*48cm |
Working time: | 24 hours/365days continuously. |
Weight (without antennae): | Up to 30KG |
Control: | Wireless Management Control |
Power Adjustment: | Multi level potentiometer |
Battery | 24V,30AH,Built-in standby battery can used for 90~120 minutes |
We could supply customized service by your detail requirements about frequencies setting. All 6 Frequency modules we can mix very flexibly.Frequency Ranges Selectable:
CDMA 800: | 851-894MHz |
GSM 900: | 925-960MHz |
DCS 1800: | 1800-1880MHz |
PHS 1900: | 1920-1990MHz |
3G 2100(UMTS): | 2110-2170MHz |
WIFI 2.4G Bluetooth: | 2400-2500MHz |
WiFi3.6G: | 3500-3600MHz |
Wi-Fi5.2G: | 5100-5500MHz |
WIFI 5.8G | 5725-5850MHz |
4G/LTE 700M: | 725-770MHz(US) |
4G/LTE 800M: | 790-826MHz(EU) |
4G Wimax: | 2300-2400MHz(US) |
4G Wimax: | 2620-2690MHz(EU) |
GPS/L1: | 1500-1600MHz |
GPS/L2: | 1200-1300MHz |
GPS/L3: | 1300-1400MHz |
GPS/L4: | 1100-1200MHz |
VHF: | 135-174MHz |
UHF: | 400-470MHz |
Lojack: | 167-175MHz |
RF315: | 315MHz |
RF433: | 433MHz |
RF868: | 868MHz |
Application:
• Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations, detention centers, interrogation rooms, courts,Reform-through-labour teams, conference rooms, movie theaters, churches, libraries, school dormitories;ect.
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:
Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year :5% of total for each years. |
