VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer

VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer

  • VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer
  • VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer
  • VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer
VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer
Product Details:
Place of Origin: China
Brand Name: DEZHEN
Certification: CE
Model Number: DZ-WT600229
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiated price
Packaging Details: carton or wooden case
Delivery Time: 25 days
Payment Terms: L/C, T/T
Supply Ability: 100pieces/month
Contact Now
Detailed Product Description
Frequency Bands: 6 Bands Function: Block Frequency
Battery: Built-in Standby Battery Style: Backpack
Switch Control: Manually Power Consumption: ≤220W
Weight: 25 Kg Size: 30 *45 *15cm
High Light:

220W Cell Phone Signal Jammer


5.8G Cell Phone Signal Jammer


VIP Protection Cellular Signal Booster

High Power VIP Protection Security Cell Phone Signal Backpack Jammer


Product Description:

This Manpack jammer is a High Power Frequency ScanJamming System, implementing the most effective and reliable RF

jamming technology and equipped with a fully-integrated broadband jamming system. Backpack jammer is highly portable

and light weight. Easy for backpack. It plays an important role to use the heavily loaded vehicle and trolley-type devices in

some extreme hard situation. The operator can carry it forward through the hills and muddy road, as well as Climbing steep

mounts and stairs avoid casualties and improve the combat efficiency.



Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.

Heat sink designing combing with the fans to make system in a cooling status


Special technology to prevent interference between each frequency band.


Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.

Frequency bands and output power selectable.


Each frequency band controlled by independent RF ON/OFF switches.


Power of each frequency band can be adjustable independently.



Output Interface Output Frequency
CH1 -WIFI2.4G: 2400-2500MHz
CH2 -WIFI5.8G: 5725-5825MHz
CH3 -GPS: 1550 -1580MHz
CH4 -GPS L2-L5:1100-1300MHz
CH5 -GSM : 850-920MHz
Jammed Signal Freqency: CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type: Backpack jammer
Output Channel: 5 output channels
Output power: 90 watt
Parameter Shielding Range: Radius 5-2000 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number 5
HS Code: 8543709200
Packing: Box
Dimension (not including antennae): 30 *45 *15cm
Antenna: Omnil Antenna
Technical Parameters:
Net Weight 12kg
Total Weight 15kg Aviation Case included
Ambient Temperature -10ºC - +50ºC
Relative Humidity ≤80%
Power Consumption ≤220W
Power Input AC100~240V,DC24V
Battery 24V,30AH,Built-in standby battery
can used for 90~180 minutes
Antenna Parameters Omni antennas,gain:4~5dBi
Switch Control Manually
Equipment Chassis Metallic Paint
Cooling system Active "smart" with integrated incoming air filter
Antennae type: External high gain Omni directional Antenna


We could supply customized service by your detail requirements about frequencies setting. 4-8

Frequency modules we can mix very flexibly.Frequency Ranges Selectable:

CDMA 800: 851-894MHz
GSM 900: 925-960MHz
DCS 1800: 1800-1880MHz
PHS 1900: 1920-1990MHz
3G 2100(UMTS): 2110-2170MHz
WIFI 2.4G Bluetooth: 2400-2500MHz
WiFi3.6G: 3500-3600MHz
Wi-Fi5.2G: 5100-5500MHz
WIFI 5.8G 5725-5850MHz
4G/LTE 700M: 725-770MHz(US)
4G/LTE 800M: 790-826MHz(EU)
4G Wimax: 2300-2400MHz(US)
4G Wimax: 2620-2690MHz(EU)
GPS/L1: 1500-1600MHz
GPS/L2: 1200-1300MHz
GPS/L3: 1300-1400MHz
GPS/L4: 1100-1200MHz
VHF: 135-174MHz
UHF: 400-470MHz
Lojack: 167-175MHz
RF315: 315MHz
RF433: 433MHz
RF868: 868MHz


Terms and conditions:

Delivery Time Schedule Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year :5% of total for each years.



Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations,

detention centers, interrogation rooms, courts,
Reform-through-labour teams, conference rooms, movie theaters, churches, libraries, school dormitories;

VIP Protection 5.8G 220W Cell Phone Signal Jammer Backpack Signal Jammer 0
