Place of Origin: | China |
Brand Name: | DEZHEN |
Certification: | CE |
Model Number: | DZ-WT702010 |
Minimum Order Quantity: | 1pc |
---|---|
Price: | negotiated price |
Delivery Time: | 3-4 weeks |
Payment Terms: | L/C, T/T |
Supply Ability: | 100pieces/month |
Design: | Customized Jammer | Type: | Outdoor Jammer |
---|---|---|---|
Packing: | Neutral Packing | Power Supply: | 50 To 60Hz, 100 To 240V AC |
Total Output Power: | 600~1200W | Jamming Range: | Up To 500m |
Feature: | Customize All Frequency Signal | Application Area: | Military Units, Prison,Police, Bomb Disposal |
Highlight: | 500m Military Gps Jammer,600W Waterproof Signal Jammer |
Durable VIP Protection Security Cell Phone Signal Waterproof Outdoor Jammer
Product Description:
This jammer use the original antenna is external double channel directional panel antennas and you can select antennas to
provide more flexibility regarding jamming coverage. The jamming coverage of this jammer is so strong that
the jamming range could reach 500m, but the jamming range is also determined by the strength of signal in
given area.
Seen from its function this one jamming device is really a good one. If you are looking for one, come here!
High quality and reasonable price is our promise.
Specification:
Output Interface | Output Frequency | RF Output watt |
CH1 | 20-80mhz | 100W |
CH2 | 80-200MHz | 100w |
CH3 | 200-500MHz | 100w |
CH4 | 500-1000MHz | 50w |
CH5 | 1000-1500MHz | 50w |
CH6 | 1500-2000MHz | 50w |
CH7 | 2000-2500MHz | 50w |
CH8 | 2500-3000MHz | 50w |
CH9 | 850-960MHz | 50w |
CH10 | 1805-1880MHz | 50w |
CH11 | 1880-1990MHz | 50w |
CH12 | 2010-2125MHz | 50w |
Total output power | 600~1200W | |
Jamming range | up to 500m,still depends on the strength signal in given area | |
Jammer Module Number | 12 | |
External double channel directional panel antennas | all the TX frequency covered down link only | |
Power supply | 50 to 60Hz, 100 to 240V AC | |
With AC adapter | (AC100-240V-DC27V) | |
Dimension | 420×480×130 mm | |
Design | Customized Jammer | |
HS Code | 8543709200 | |
Packing | Neutral Packing |
We could supply customized service by your detail requirements about frequencies setting. All 6-12
Frequency modules we can mix very flexibly.
CDMA 800: | 851-894MHz |
GSM 900: | 925-960MHz |
DCS 1800: | 1800-1880MHz |
PHS 1900: | 1920-1990MHz |
3G 2100(UMTS): | 2110-2170MHz |
WIFI 2.4G Bluetooth: | 2400-2500MHz |
WiFi3.6G: | 3500-3600MHz |
Wi-Fi5.2G: | 5100-5500MHz |
WIFI 5.8G | 5725-5850MHz |
4G/LTE 700M: | 725-770MHz(US) |
4G/LTE 800M: | 790-826MHz(EU) |
4G Wimax: | 2300-2400MHz(US) |
4G Wimax: | 2620-2690MHz(EU) |
GPS/L1: | 1500-1600MHz |
GPS/L2: | 1200-1300MHz |
GPS/L3: | 1300-1400MHz |
GPS/L4: | 1100-1200MHz |
VHF: | 135-174MHz |
UHF: | 400-470MHz |
Lojack: | 167-175MHz |
RF315: | 315MHz |
RF433: | 433MHz |
RF868: | 868MHz |
Application:
It can be used to prevent terrorists remotely controlling the bomb bursting points in military protection
zone,government buildings and some other important places. It can also make the criminals hidden in the
military protection zone not communicate with the outside gang to leak the confidence.
It can be applied that the common used telecommunication frequency will be blocked when the Police
arrest the criminals in order to prevent the criminals gang or Police insider leaking the confidence through
the wireless equipments ,so that the arrest collapsed. It also make the criminals not be able to remotely
control the bomb in the key entrance of the building so that Police can quickly access to the building and
round up the criminals to avoid the casualties.
Protecting the boarder and army patrol from the attack of road- side bomb RCIED denotated by the
terrorists.
Terms and conditions:
Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year : 5% of total for each years. |
