Shenzhen Dezhen Telecommunication Technology Co.,Ltd
professional manufacturer of mobile signal jammer ,high power jammer and min signal booster!
 |
| Place of Origin: | China |
| Brand Name: | DEZHEN |
| Certification: | CE.FCC. |
| Model Number: | DZ-WT701841 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiated price |
| Delivery Time: | 3-10 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2000 pcs per years |
| Type: | Outdoor Jammer | Weight Of Product: | 25kg |
|---|---|---|---|
| Total Output Power: | 300W | Jamming Range: | Up To 300m |
| Packing: | Neutral Packing | Signal Jammer For: | All Cell Phone Signal Frequency |
| Antenna Type: | Directional Antenna Or Omini-directional Antenna | Application Area: | Military Units, Prison,Police, Bomb Disposal |
| Highlight: | Cell Phone Signal Jamming Device,GSM Cell Phone Jammer |
||
300W Output Power Waterproof Directional Antennas Cell Phone Frequency Jammer
Product Description:
This is a high power efficient jamming device can be used to block unwanted signals in occasions such as VIP convoy protection,
military rehearse, municipal hall, police check point, prison, disposal bombs, as well as vehicle mounted to block remote controlled
explosive devices.With jamming distance up to 300 meters,this high power signal jammer is very competative.
Features:
1,Ethernet IP Remote Monitoring System available
2,RF module alarm type: Temperature alarm, Over power alarm, Standing wave alarm.
Specifications:
| Output Interface | Output Frequency |
| CH1 | CDMA: 851-960MHz |
| CH2 | GSM: 925-960MHz |
| CH3 | DCS: 1805-1880MHz |
| CH4 | PCS: 1880-1990MHz |
| CH5 | 3G: 2110MHz-2170MHz |
| CH6 | 4G Wimax: 2300-2400MHz |
| Jammed Signal Freqency: | CDMA,GSM,DCS,PCS,3G,4G |
| Type: | Waterproof jammer |
| Output Channel: | 6 output channels |
| Antenna: | Omni Antenna |
| Transmission Power: | Integrated Equipment:300W, each channel:50W |
| Parameter Shielding Range: | 25-300 meters (depending on the distance of base station in an open filed) |
| Jammer Module Number | 6 |
| HS Code: | 8543709200 |
| Packing: | Box |
| Dimension (not including antennae): | 30 *45 *15cm |
| Technical Parameters: | |
| Net Weight | 25kg |
| Total Weight | 30 kg Aviation Case included |
| Ambient Temperature | -10ºC - +50ºC |
| Relative Humidity | ≤80% |
| Power Consumption | ≤360W |
| Power Input | AC100~240V,DC24V |
| Battery | 24V,30AH,Built-in standby battery can used for 90~180 minutes |
| Antenna Parameters | Omni antennas,gain:4~5dBi |
| Switch Control | Manually |
| Equipment Chassis | Metallic Paint |
| Cooling system | Active "smart" with integrated incoming air filter |
| Antennae type: | External high gain Omni directional Antenna |
We could supply customized service by your detail requirements about frequencies setting. All 6
Frequency modules we can mix very flexibly.
| CDMA 800: | 851-894MHz |
| GSM 900: | 925-960MHz |
| DCS 1800: | 1800-1880MHz |
| PHS 1900: | 1920-1990MHz |
| 3G 2100(UMTS): | 2110-2170MHz |
| WIFI 2.4G Bluetooth: | 2400-2500MHz |
| WiFi3.6G: | 3500-3600MHz |
| Wi-Fi5.2G: | 5100-5500MHz |
| WIFI 5.8G | 5725-5850MHz |
| 4G/LTE 700M: | 725-770MHz(US) |
| 4G/LTE 800M: | 790-826MHz(EU) |
| 4G Wimax: | 2300-2400MHz(US) |
| 4G Wimax: | 2620-2690MHz(EU) |
| GPS/L1: | 1500-1600MHz |
| GPS/L2: | 1200-1300MHz |
| GPS/L3: | 1300-1400MHz |
| GPS/L4: | 1100-1200MHz |
| VHF: | 135-174MHz |
| UHF: | 400-470MHz |
| Lojack: | 167-175MHz |
| RF315: | 315MHz |
| RF433: | 433MHz |
| RF868: | 868MHz |
Application:
Prisons, Military or Government buildings, and other sensitive locations where the mobile phone signals are not allowed.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
Contact Person: Mr. Yuen (+86 13316806155)
Tel: +86 13316806155
Fax: 86-133-16806155
