Metal Enclosure 7 Bands 4G Mobile Phone Jammer

Metal Enclosure 7 Bands 4G Mobile Phone Jammer

  • Metal Enclosure 7 Bands 4G Mobile Phone Jammer
  • Metal Enclosure 7 Bands 4G Mobile Phone Jammer
  • Metal Enclosure 7 Bands 4G Mobile Phone Jammer
  • Metal Enclosure 7 Bands 4G Mobile Phone Jammer
Metal Enclosure 7 Bands 4G Mobile Phone Jammer
Product Details:
Place of Origin: CHINA
Brand Name: DEZHEN
Model Number: DZ-3067C-HGA
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Customized product
Delivery Time: 7-10 Days
Payment Terms: L/C, T/T, Western Union
Contact Now
Detailed Product Description
Total Output Power: 180W Jamming Range: Radius 100~300 Meters
Frequency: 4G LTE1/LTE2,PCS1900,4G WIMAX2 Feature: Waterproof
Packing: Neutral Packing Weight Of Product: 22Kg
High Light:

7 bands jail project jammer

,

4g cell phone jammer

4G jammer , 7 Bands Mobile Phone Jammer Waterproof for Jail Project Jammer



Product Description

The product that you are viewing is the Waterproof Wireless Software Controlled Cell Phone Jammer, which is developed specially for prisons and other large, sensitive facilities, such as military installations and government compounds. And as applying high technology this jamming system can be controlled remotely with activation and deactivation of the system is carried out only by using a Wireless Control Unit by Computer.

And apart from the above characteristic, this jammer device is constructed inside a special metal enclosure, incorporating an efficient "smart active" cooling system with incoming air filters, which enables the system to operate 24 hours a day and 7 days a week continuously even in hot weather. And the secure design ensures that the prison inmates and unauthorized prison personnel cannot tamper with the safe and continuous operation of the system.

If you are looking for one just come here and pick up one. We will of course offer you the high quality jammer at the best price.

Features:

  • High power
  • Waterproof design
  • With a extreme hard metal enclosure
  • Shielding range can be regulated by the computer remotely
  • Alarming system design in case of equipment abnormal problem and people's sabotage, showed as below:
  • The computer makes an alarming sound and e-mail notification to the administrator

a) RF line is artificially cut
b) Equipment doors exception open
c) Modules damaged.

  • Easy outdoor installation and remote controlled operation
  • Any computer with COM port can be available for the program software.
  • It can be controlled in real time including RF output power and separate module as well as all the jammer’s working status.
  • Specially designed shockproof ,Waterproof and RF shielded internal metal enclosure
  • Smart active cooling system enables unlimited continuous operation in very hot temperatures with fans design.
  • Module design based on high power RF amplifiers with VSWR and temperature self-protection technology.


At a Glance:

  • Each unit can jam up to five frequency bands simultaneously.
  • Continuous operation, even in hot climates, with no time limit.
  • Secure design to avoid sabotage.
  • (VSWR) circuit protection to ensure system will not burn out should there be antenna short circuiting or disconnection
  • Antenna type options, directional or omni antennas option.
  • Controlled via a computer,
  • E-mail system.
  • Turn on/off the jammer via computer
  • Adjust the output power via computer.
  • Turn on/off the jammer module separately.
  • Special additional housing for all weather protection.
  • UPS and battery backup in case of mains power failure

Application:

  • Prisons and other large sensitive locations such as military or
  • governmental compounds. It can also use in Oil and Gas
  • Storage Facilities and fields, Security Services, Military Units,
  • Secret Services, Museums, Border Patrol and Drug Enforcement,
  • Customs, etc.


Product Notes:

  • The shielding range of the device will be determined by the local signal strength. In different situation, it will be with different performance.
  • Please try to put the device in a higher position while it is working .Itwill be better. The suggested height is about 8M. To avoid the loss of function of the device, please try to avoid the device placed on or the metal materials.
  • Do not turn on the power before the antennas is installed, If the antenna is not properly installed in accordance with the manuals, the shielding range will be not so good. Make sure the correct installation before turn on the power.


Specification:



Output Interface Output Frequency RF Output watt
CH1 758-803MHz 30W
CH2 851-869MHz 30W
CH3 869-894MHz 30W
CH4 1930-1990MHz 20W
CH5 2110-2155MHz 20W
CH6 700-806MHz 30W
CH7 2500-2690MHz 20W
Total output power 180W
Jamming range Radius 100~300 meters (-75dBm@ Antennas)
Jammer Module Number 7
Cooling System Systematic Smart Cooling System
System Protection VSWR, Over-voltage, Over-current
Remote Control (Option) Full System Operation Control
Power supply 50 to 60Hz, 100 to 240V AC
With AC adapter (AC100-240V-DC27V)
Design Customized Jammer
HS Code 8543709200
Packing Neutral Packing
Dimension 520 x 340 x 200mm
Weight 22kg
