Directional Antennas 1200W Waterproof Outdoor Signal Jammer

Directional Antennas 1200W Waterproof Outdoor Signal Jammer

  • Directional Antennas 1200W Waterproof Outdoor Signal Jammer
  • Directional Antennas 1200W Waterproof Outdoor Signal Jammer
  • Directional Antennas 1200W Waterproof Outdoor Signal Jammer
Directional Antennas 1200W Waterproof Outdoor Signal Jammer
Product Details:
Place of Origin: China
Brand Name: DEZHEN
Certification: CE.FCC
Model Number: DZ-WT702011
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: negotiated price
Delivery Time: 3-4 weeks
Payment Terms: L/C, T/T
Supply Ability: 100 pieces/month
Contact Now
Detailed Product Description
Design: Customized Jammer Type: Outdoor Jammer
Packing: Neutral Packing Power Supply: 50 To 60Hz, 100 To 240V AC
Total Output Power: 600~1200W Jamming Range: Up To 500m
Feature: Customize All Frequency Signal Application Area: Military Units, Prison,Police, Bomb Disposal
High Light:

1200W Cell Phone Signal Jammer

,

Directional Antennas Signal Jamming Device



Military VIP Protection Security Waterproof Outdoor Jammer High Power Cell Phone Signal Jammer



Features:

1. Each Jammer can jam up to 8 frequencies simultaneously.
2. Supports high gain directional antennas for covering long range as far as possible
3. Specially equipped with IP65 Waterproof and solid housing for all weather protection.
4. Supports Remote control for switching ON/OFF Jammer
5. Supports Remote Access Control (computer internet software control) for controlling each band power.
Failure alarms and running time.Jammer Failure Alarms: Such as the cabinet opened maliciously, RF cables
cut off deliberately, Modules failure,Temperature problems, the failure alarms will be sent to software.


Specification:

  • Affected Frequency Ranges: (12bands option)
Output Interface Output Frequency RF Output watt
CH1 20-80mhz 100W
CH2 80-200MHz 100w
CH3 200-500MHz 100w
CH4 500-1000MHz 50w
CH5 1000-1500MHz 50w
CH6 1500-2000MHz 50w
CH7 2000-2500MHz 50w
CH8 2500-3000MHz 50w
CH9 850-960MHz 50w
CH10 1805-1880MHz 50w
CH11 1880-1990MHz 50w
CH12 2010-2125MHz 50w
Total output power 600~1200W
Jamming range up to 500m,still depends on the strength signal in given area
Jammer Module Number 12
External double channel directional panel antennas all the TX frequency covered down link only
Power supply 50 to 60Hz, 100 to 240V AC
With AC adapter (AC100-240V-DC27V)
Dimension 420×480×130 mm
Design Customized Jammer
HS Code 8543709200
Packing Neutral Packing


We could supply customized service by your detail requirements about frequencies setting. All 6-12
Frequency modules we can mix very flexibly.

CDMA 800: 851-894MHz
GSM 900: 925-960MHz
DCS 1800: 1800-1880MHz
PHS 1900: 1920-1990MHz
3G 2100(UMTS): 2110-2170MHz
WIFI 2.4G Bluetooth: 2400-2500MHz
WiFi3.6G: 3500-3600MHz
Wi-Fi5.2G: 5100-5500MHz
WIFI 5.8G 5725-5850MHz
4G/LTE 700M: 725-770MHz(US)
4G/LTE 800M: 790-826MHz(EU)
4G Wimax: 2300-2400MHz(US)
4G Wimax: 2620-2690MHz(EU)
GPS/L1: 1500-1600MHz
GPS/L2: 1200-1300MHz
GPS/L3: 1300-1400MHz
GPS/L4: 1100-1200MHz
VHF: 135-174MHz
UHF: 400-470MHz
Lojack: 167-175MHz
RF315: 315MHz
RF433: 433MHz
RF868: 868MHz


Application:
It can be applied that the common used telecommunication frequency will be blocked when the Police

arrest the criminals in order to prevent the criminals gang or Police insider leaking the confidence through

the wireless equipments ,so that the arrest collapsed. It also make the criminals not be able to remotely

control the bomb in the key entrance of the building so that Police can quickly access to the building and

round up the criminals to avoid the casualties.

It can be used to prevent terrorists remotely controlling the bomb bursting points in military protection

zone,government buildings and some other important places. It can also make the criminals hidden in the

military protection zone not communicate with the outside gang to leak the confidence.



Accessories

  • High Power Cell Phone Signal Jammer
  • Antennas
  • Power cable



Terms and conditions:

Delivery Time Schedule Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year : 5% of total for each years.



Directional Antennas 1200W Waterproof Outdoor Signal Jammer 0
