GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands

GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands

    • GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands
    • GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands
    • GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands
    • GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands
  • GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands

    Product Details:

    Place of Origin: China
    Brand Name: DEZHEN
    Certification: CE
    Model Number: DE-WP-1-05

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: negotiated price
    Delivery Time: 25 days
    Payment Terms: L/C, T/T
    Supply Ability: 100pieces/month
    Contact Now
    Detailed Product Description
    Total Output Power: 300~600W Jamming Range: Up To 500m, The Jamming Radius Still Depends On The Strength Signal In Given Area
    Power Supply: 50 To 60Hz, 100 To 240V A Feature: Waterproof Adjustable High Power
    Dimension: 420×480×130 Mm Advantage: Each Band Can Adjust RF Power Output Level Or Turn Off Without Influencing The Other Bands’ Operation
    External Double Channel Directional Panel Antennas: All The TX Frequency Covered Down Link Only Affected Frequency Ranges: 6bands Option
    High Light:

    GSM Cell Phone Jammer

    ,

    RF Cellular Gps Signal Blocker

    GSM CDMA 3G 4glte WiFi GPS VHF UHF Omni Directional Antennas Cell Phone Scrambler 6-10 Bands



    Product Description:

    The 6-10 Bands Waterproof Adjustable High Power All Cell Phone and Wifi UHF VHF Jammer for Prison is specially customized to accommodate a fully integrated broad band jamming system which provides the ultimate solution for Prison Military and Police convoys or VIP protection. The 6 modules are controlled separately and they also can work simultaneously.


    Each module with antenna can be used as a single jammer. The prison jammer is waterproof and portable, the jammer case is our patent design, it can be installed in desert and more rain of bad weather. The Frequency band is optional. And the high power jammer is with excellent heat dispersion.Frequency bands and output power selectable.



    Each frequency band controlled by independent RF ON/OFF switches.Power of each frequency band can be adjustable independently.Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection. Antenna type options, directional or Omni-directional antennas option. Easy operation and installation.Keep for upgrade module installation.Working 24 hours/365days continuously.



    Specification

    Affected Frequency Ranges: (6bands option)



    Output Interface Output Frequency RF Output watt
    CH1 CDMA 800: 850 to 894MHz 50-100W
    CH2 GSM 900: 925 to 960MHz 50-100W
    CH3 GSM 1800: 1805 to 1880MHz (DCS) 50-100W
    CH4 GSM 1900: 1920 to 1990MHz (PCS) 50-100W
    CH5 3G: 2110 to 2170MHz 50-100W
    CH6 4G LTE: (USA:725-770MHz) or (Europe:790-826MHz) 50-100W
    CH7 4G Wimax: (USA:2345-2400MHz) or (Europe:2620-2690MHz) 50-100W
    CH8 WiFi: 2400-2500MHz 50-100W
    CH9 VHF: 136-174MHz 50-100W
    CH10 UHF: 400-470MHz 50-100W
    Total RF Power 300-600Watt,
    Power supply 50 to 60Hz, 100 to 240V AC
    Shielding area 20-500m @ according to signal density of mobile network
    Jammer Module Number 5-10
    Cooling System Systematic Smart Cooling System
    Dimension 420×480×130 mm
    Antenna: External double channel directional panel antennas all the TX frequency covered down link only
    Remote Control (Option) Each band can work independently



    Accessories

    • High Power Cell Phone Signal Jammer
    • Antennas
    • Power cable



    Monitor software function: (Option)

    · Remote control switches of each machine.
    · Remote viewing each machine working state.
    · The power output of each machine remote adjustment.
    · Remote viewing offline log of each machine.
    · Mail receiving each machine working state.
    · The system can set permissions to log on.



    Terms and conditions:



    Delivery Time Schedule Delivery time is 1 or 2 months, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
    Payment Terms 40% advance, 40% after one month,20% before shipping.
    Terms of Delivery FOB HONGKONG/ USA.
    Warranty 36 months.
    Software Updates Free software updates will be provided for a period of 36 months.
    Extended Warranty After 4th Year : 5% of total for each years.
